Learn MoreWDS Series Electromagnet
Product Description
The WDS electromagnet is a C-Frame, variable air gap magnetic field generation equipment with each pole being adjustable. From the excitation of the excitating power source, the field vector forms a closed loop, and a high uniform magnetic field can be generated between two poles, and the field direction is along the axial direction of pole caps. All WD electromagnets are equipped with a pair of standard replaceable pole caps made of purity iron, which can be replaced to suit to individual experiment requirements. The pure-iron structure is suitable for coils heat dissipation, and the option of cooling water system is also available for extend the operating time. -
Learn MoreSingle-Axis Helmholtz Coil
Product Description
The Helmholtz coil is a device composed of two sets of identical circular coils placed parallel to the same axis and run current in the same direction to generate a uniform magnetic field. Helmholtz coils can be customized by through adjusting the coil diameter, required magnetic field, working time, structural requirements, and dissipation requirements (air cooling or water cooling). -
Learn MoreVSM
Product Description
A vibrating sample magnetometer(VSM) is an instrument that is used to measure magnetic properties. It is also called a Foner magnetometer or M-H Curve Hysteresis Graph Test System.
VSM is composed of a master device, an electromagnet, a vibrator, a computer. The electromagnet source, the vibrator source, the magnetic moment measuring unit and the magnetic field measuring unit which all controlled by MPU (AT89C52) constitute the instrument. The instrument communicates to the computer with the standard RS-232-C serial interface, then enhanced systematicness of the instrument and operability of the hardware. Operating functions of the special complement software is powerful and software is used conveniently. -
Learn MoreStandard Permanent Magnet
Product Description
A standard Magnet is a kind of permanent magnet which is specially designed for Hall Element Calibration,capable of generating a stable and uniform magnetic field between two magnetic pole.
The Standard Magnets are manufactured with high-performance rare earth materials to ensure long-term maintenance of its excellent magnetic properties, and which is widely used in a variety of fields requiring accurate magnetic field calibration, such as laboratories, metrology institutes and industrial testing equipment -
Learn MoreSolenoid Coils
Product Description
A solenoid coil is an efficient electromagnetic device, consisting of conductor wires made of highly conductive materials winding in a tight spiral shape, capable of generating a uniform and strong magnetic field. Our solenoid has the characteristics of good uniformity, small size and high magnetic field.
The solenoid is suitable for coils heat dissipation, and the option of cooling water system is also available for extend the operating time. and can be designed and produced according to user's application conditions、coil size、structural and magnetic field requirements. -
Learn MoreYP Series DC Power Supply
Product Descriptions
The DC power supply is a bipolar constant current power supply with high stability, high accuracy, high linearity and low ripple noise;
Relay-reversal direction controlled by the microprocessor with 5 options to delay time;
Reversal current surge: Less than 1 mA;
Three linear sweep modes including I, I-III, I-III-I quadrants;
Provided with built-in RS-232 or USB port and the relative conversion port;
A set of computer interface command (for RS-232 or USB port);
Timing continuous trigger output during sweeping. -
Learn MoreHALL EFFECT MEASUREMENT SYSTEM
Product Descriptions
HALL EFFECT MEASUREMENT SYSTEM is used to measure the important parameters of Semiconductor Materials such as Carrier Concentration, Mobility, Resistivity, and Hall Coefficient, and so on. These parameters must be grasped and controlled in advance in order to understand the electrical characteristics of semiconductor materials. Therefore, the Hall Effect Measurement System is an indispensable tool for understanding and studying the electrical characteristics of Semiconductor Devices and Semiconductor Materials. The experimental results are automatically calculated by the software, and the Bulk Carrier Concentration, Sheet Carrier Concentration, Mobility, Resistivity, Hall Coefficient, Magneto-Resistance, and other parameters can be obtained at the same time. -
Learn MoreFlux meter
Product Descriptions
The third-generation smart high precision flux meter is controlled by a microprocessor. It uses electronic integral principle, automatic digital suppression adjustment drift system. Display the measured magnetic flux and magnetic field intensity with a color display.It can measure the total magnetic flux and get the values of magnetic flux density and magnetic field strength. The flux meter is a valuable component in magnetizing machines, manual and automatic magnet detection and classification, and hysteresis loop measurement systems.
Learn More About Our Products
-
HALL EFFECT MEASUREMENT SYSTEM
HALL EFFECT MEASUREMENT SYSTEM is used to measure the important parameters of Semiconductor Materials such as Carrier Concentration, Mobility, Resistivity, and Hall Coefficient, and so on. These parameters must be grasped and controlled in advance in order to understand the electrical characteristics of semiconductor materials. Therefore, the Hall Effect Measurement System is an indispensable tool for understanding and studying the electrical characteristics of Semiconductor Devices and Semiconductor Materials. The experimental results are automatically calculated by the software, and the Bulk Carrier Concentration, Sheet Carrier Concentration, Mobility, Resistivity, Hall Coefficient, Magneto-Resistance, and other parameters can be obtained at the same time.
-
VSM
A vibrating sample magnetometer(VSM) is an instrument that is used to measure magnetic properties. It is also called a Foner magnetometer or M-H Curve Hysteresis Graph Test System. <br/> VSM is composed of a master device, an electromagnet, a vibrator, a computer. The electromagnet source, the vibrator source, the magnetic moment measuring unit and the magnetic field measuring unit which all controlled by MPU (AT89C52) constitute the instrument. The instrument communicates to the computer with the standard RS-232-C serial interface, then enhanced systematicness of the instrument and operability of the hardware. Operating functions of the special complement software is powerful and software is used conveniently.
-
WDS Series Electromagnet
The WDS electromagnet is a C-Frame, variable air gap magnetic field generation equipment with each pole being adjustable. From the excitation of the excitating power source, the field vector forms a closed loop, and a high uniform magnetic field can be generated between two poles, and the field direction is along the axial direction of pole caps. All WD electromagnets are equipped with a pair of standard replaceable pole caps made of purity iron, which can be replaced to suit to individual experiment requirements. The pure-iron structure is suitable for coils heat dissipation, and the option of cooling water system is also available for extend the operating time.
-
Gauss Meters
One-dimensional High-precision Digital Gauss meters is suitable for most applications that require high testing accuracy and resolution. Measurements range from DC to 100KHZ AC magnetic fields. Automatic zero, automatic range. Hold mode selectable maximum, minimum, peak and valley values. The instrument can simultaneously measure and display 6 parameters. The measurement units can be selected from Gauss, millitesla, A/M, or Oe.
-
YPD Series DC Power Supply
This power supply is a high stability bipolar constant current power supply (smooth zero crossing commutation without delay). The power supply adopts a linear power supply structure, with high output current stability, low ripple and noise. The output current of the power supply can be continuously changed between positive and negative rated maximum current, and the current is smooth and continuous zero, which can generate a smooth and stable magnetic field in the electromagnet or coil. With our high precision Gauss meter and probe (optional), the power supply can operate in magnetic field mode. The magnetic field value can be directly set in magnetic field mode,The power supply will adjust the output current to make the electromagnet quickly reach the set magnetic field, convenient and fast, and the magnetic field is stable.It can control the field independently or scan the magnetic field continuously. The current mode and magnetic field mode can be switched at any time according to the need, and the operation is flexible.
-
Solenoid Coils
A solenoid coil is an efficient electromagnetic device, consisting of conductor wires made of highly conductive materials winding in a tight spiral shape, capable of generating a uniform and strong magnetic field. Our solenoid has the characteristics of good uniformity, small size and high magnetic field.<br/> The solenoid is suitable for coils heat dissipation, and the option of cooling water system is also available for extend the operating time. and can be designed and produced according to user's application conditions、coil size、structural and magnetic field requirements.
-
Flux-gate magnetometer
Flux-gate magnetometer is a that accurately measures weak static and low-frequency vector magnetic fields,which has the characteristics of high stability, high linearity, high-precision and full digitization. Compared with magnetic field measurement instruments based on Hall effect principle or magnetoresistance effect principle, it is the best choice for measuring weak magnetic fields. It has digital and analog signal output, and a unique CAN bus network interface suitable for multi array magnetic field testing. It is widely used in scientific research, military industry, aerospace and other departments
-
Single-Axis Helmholtz Coil
The Helmholtz coil is a device composed of two sets of identical circular coils placed parallel to the same axis and run current in the same direction to generate a uniform magnetic field. Helmholtz coils can be customized by through adjusting the coil diameter, required magnetic field, working time, structural requirements, and dissipation requirements (air cooling or water cooling).
-
The dynamic magnetic field active geomagnetic shielding system
The dynamic magnetic field shielding effect can reach a higher level (better than 5 nT). By using AC current to generate a magnetic field, it has higher DC and AC magnetic field shielding efficiency, more accurate trajectory tracking function, larger range, and higher response speed. The ability to generate magnetic fields with three components X, Y, and Z within the range of (0-100000 nT) magnetic fields can be precise up to 5 nT, making products and experiments in scientific research, military industry, and medical care extremely meaningful and widely used.
